High TG Black Soldermask Prototype Multi Layer Pcb Laser Drill Communicate Electronics Board
Key Specifications/Special Features:
Multilayer ceramic PCBs
PCBs material: FR-4, 0.5oz - 6oz copper
0.45 to 3.2mm thickness
Minimum line width and line spacing: 4mil/4mil
Minimum hole diameter: 0.2mm
Maximum panel size: 680 x 1280mm
Surface finishing: - HAL, alpha level, gold plating, ENTech
- HAL or tin and gold plating
Solder mask type: liquid photoimageable solder mark
Precision V-cut or routing for panel form design
OEM orders for SMT and A/I assembly projects accepted
Gerber file preferred
Please note the following information are for your reference on our manufacturing capability, not for inquiries on quotations
We will offer our best prices if you can send your own PCB design
Product Details:
Place of Origin:China
Brand Name:XCE
Certification:CE,ROHS, FCC,ISO9008,SGS,UL
Model Number:XCEH
Minimum Order Quantity:1pcs
Price:negotiation
Packaging Details:inner: vacuum-packed bubble bag outer: carton box
Delivery Time:5-10 days
Payment Terms:T/T,Western union
Supply Ability:1, 000, 000 PCS / week
Advantage Highlights
- Specialized in 2- to 32-layer PCB
- ISO 9001-, ISO 14001- and ISO/TS 16949-certified
- Products are UL- and RoHS-certified
- Partner for over 2000 small- and medium-scale customers
- Two factory bases totaling 22,000 square meters
- Less than 12-hours quick response to inquiries
- Widely acclaimed and satisfying services
- Over 66% of PCBs are exported to international markets
-
Parameter:
| o | Item | Data |
| 1 | Layer: | 1 to 24 layers |
| 2 | Material type: | FR-4, CEM-1, CEM-3, High TG, FR4 Halogen Free, Rogers |
| 3 | Board thickness: | 0.20mm to 3.4mm |
| 4 | Copper thickness: | 0.5 OZ to 4 OZ |
| 5 | Copper thickness in hole: | >25.0 um (>1mil) |
| 6 | Max. Board Size: | (580mm×1200mm) |
| 7 | Min. Drilled Hole Size: | 4mil(0.1mm) |
| 8 | Min. Line Width: | 3mil (0.075mm) |
| 9 | Min. Line Spacing: | 3mil (0.075mm) |
| 10 | Surface finishing: | HASL / HASL lead free, HAL, Chemical tin, Chemical Gold, Immersion Silver/Gold, OSP, Gold plating |
| 11 | Solder Mask Color: | Green/Yellow/Black/White/Red/Blue |
| 12 | Shape tolerance: | ±0.13 |
| 13 | Hole tolerance: | PTH: ±0.076 NPTH: ±0.05 |
| 14 | Package: | Inner packing: Vacuum packing / Plastic bag,Outer packing: Standard carton packing |
| 15 | Certificate: | UL,SGS,ISO 9001:2008 |
| 16 | Special requirements: | Buried and blind vias+controlled impedance +BGA |
| 17 | Profiling: | Punching, Routing, V-CUT, Beveling |
Place of Origin: |
Guangdong China (Mainland) |
Brand Name: |
XCE |
Model Number: |
XCEPCB008 |
Base Material: |
FR4 |
Copper Thickness: |
0.3-3oz |
Board Thickness: |
0.3-6mm |
Min. Hole Size: |
0.2mm |
Min. Line Width: |
3mil |
Min. Line Spacing: |
3mil |
Surface Finishing: |
HASL, OSP, Immersion Gold/Au, Immersion silver, etc. |
Solder mask: | Green |
PCB Standard: |
IPC-A-610 E Class II-III |
Wrap and twist: |
5% |
Layer Count: |
1-22 |
profiling punching: |
Routing, V-CUT, Beveling |
Max board size: |
1200mm*600mm |
Hole tolerance: |
PTH:±0.075,NTPH:±0.05 |
PCB Tolerance of finished thickness: |
±5% |
PCB: |
Customized |
Product name: |
pcb |
Benefits:
High dielectric constant for circuit size reduction
Low loss. Ideal for operating at X-band or below
Tight εr and thickness control for repeatable circuit performance
Typical Applications:
Space Saving Circuitry
Patch Antennas
Satellite Communications Systems
Power Amplifiers
Aircraft Collision Avoidance Systems
Ground Radar Warning Systems
Competitive Advantage:
1) With UL,ROHS,ISO,IPC
2).Lead time:3-10 working days
3)Competitive price best quality
4)Rich 20 years experience in High Tg Multilayer PCB
| Items | | Manufacturing Capabilities | Remarks |
| Number of Layers | – | 1-10 layers | For orders above 10 layers,please view the below “Standard PCB” or contact our sales rep. |
| Material | – | FR-4,Aluminum | For Flex, Rigid-flex, Metal-based (Aluminum etc.,), HDI, Halogen-free, High Tg, etc.,please view the below “Standard PCB” or contact sales rep. |
| Maximum PCB Size(Dimension) | – | 500*1100mm (min 5*6mm) | Any sizes beyond this dimension, please view the below “Standard PCB” or contact sales rep. |
| Board Size Tolerance(Outline) | – | ±0.2mm/±0.5mm | ±0.2mm for CNC routing, and ±0.5mm for V-scoring. |
| Board Thickness | | 0.2-2.4mm | 0.2,0.4, 0.6, 0.8, 1.0, 1.2, 1.6, 2.0, 2.4mm. Please view the below “Standard PCB” or contact us if your board exceeds these. |
| Board Thickness Tolerance(t≥1.0mm) | – | ±10% | Normally “+ Tolerance” will occur due to PCB processing steps such as electroless copper, solder mask and other types of finish on the surface. |
| Board Thickness Tolerance(t<1.0mm) | – | ±0.1mm |
| Min Trace | | 0.1mm/4mil | Min manufacturable trace is 4mil(0.1mm), strongly suggest to design trace above 6mil(0.15mm) to save cost. |
| Min Spacing | Min manufacturable spacing is 4mil(0.1mm), strongly suggest to design spacing above 6mil(0.15mm) to save cost. |
| Outer Layer Copper Thickness | | 1oz/2oz/3oz(35μm/70μm/105μm) | Also known as copper weight. 35μm=1oz, 70μm=2oz, 105μm=3oz. Please view the below “Standard PCB” or contact us if you need copper weight greater than 3oz. |
| Inner Layer Copper Thickness | | 1oz/1.5oz(35μm/50μm) | Inner copper weight as per customer’s request for 4 and 6 layers. Please contact us if you need copper weight greater than 1.5oz. |
| Drill Sizes (CNC) | | 0.2-6.3mm | Min drill size is 0.2mm, max drill is 6.3mm. Any holes greater than 6.3mm or smaller than 0.3mm will be subject to extra charges. |
| Min Width of Annular Ring | | 0.15mm(6mil) | For pads with vias in the middle, Min width for Annular Ring is 0.15mm(6mil). |
| Finished Hole Diameter (CNC) | | 0.2mm-6.2mm | The finished hole diameter will be smaller than size of drill bits because of copper plating in the hole barrels |
| Finished Hole Size Tolerance(CNC) | – | ±0.08mm | For example, if the drill size is 0.6mm, the finished hole diameter ranges from 0.52mm to 0.68mm will be considered acceptable. |
| Solder Mask | | LPI | Liquid Photo-Imageable is the mostly adopted. Thermosetting Ink is used in the inexpensive paper-based boards. |
| Minimum Character Width(Legend) | | 0.15mm | Characters of less than 0.15mm wide will be too narrow to be identifiable. |
| Minimum Character Height (Legend) | – | 0.8mm | Characters of less than 0.8mm high will be too small to be recognizable. |
| Character Width to Height Ratio (Legend) | – | 1:5 | In PCB silkscreen legends processing, 1:5 is the most suitable ratio |
| Minimum Diameter of Plated Half Holes | – | 0.6mm | Design Half-Holes greater than 0.6mm to ensure better connection between boards. |
| Surface Finishing | | HASL with lead
HASL lead free
Immersion gold,OSP | The most popular three types of PCB surface finish. Please view the below “Standard PCB” or contact us for other finishes. |
| Solder Mask | | Green ,Red, Yellow, Blue, White ,Black | No extra charge (Green, Red, Yellow, Blue) |
| Silkscreen | | White, Black, None | No extra charge. |
| Panelization | | V-scoring,
Tab-routing,
Tab-routing with Perforation (Stamp Holes) | Leave min clearance of 1.6mm between boards for break-routing. For V-score panelization, set the space between boards to be zero. |
| Others | – | Fly Probe Testing (Free) and A.O.I. testing(free), ISO 9001:2008 ,UL Certificate | No extra charge. |
| Items | Sample | High Volume |
| Single Sided PCB | 1-3 | 4-7 |
| Double Sided PCB | 2-5 | 7-10 |
| Multi-layer PCB | 7-8 | 10-15 |
| PCB Making & Assembly | 8-15 | 15-20 |
